ConceptPatio 155
Sophistication for quality and insulation
- Uw
- 0.99W/m²K
- Max. vent height
- 3500mm
- Max. fixed-panel weight
- 1500kg
01 — Overview
Overview
ConceptPatio 155 is an insulated classic sliding and lift-and-slide system designed to create maximum glazed areas with increased comfort. It can be upgraded to High Insulation for low-energy buildings, and a special monorail variant carries the Swiss Minergie® component label.
It is offered in many opening types, with a low-threshold option for comfortable transitions and optional automation. The lift-and-slide version allows very large glazed doors with a slim, minimalist interlock, and the system is compatible with CS 77 and meets burglar-resistance class WK2 (RC2).
02
Specifications
Performance
EX-06.01- Uw
- 0.99 W/m²K
- Air permeability
- Class 4 (600 Pa)
- Water tightness
- Class E900 (900 Pa)
- Wind resistance
- Class C4 (1600 Pa)
- Acoustics Rw (C;Ctr)
- 42 (-1;-3) dB
- Opening and closing durability
- Class 4
- Burglar resistance
- RC2, PAS 24
Dimensions
EX-06.02- Vent height
- 500–3500 mm
- Vent width
- 700–2700 mm
- Frame depth
- 155 mm (2-rail) / 242 mm (3-rail)
- Glazing thickness (vent)
- 4–52 mm
03
Documents
Gallery
01 / 04
02 / 04
03 / 04
04 / 04
