HiFinity
Infinite views
- Uw
- 0.8W/m²K
- Max. vent weight
- 750kg
- Min. visible width
- 8mm
Overview
The ultra-slim design of the HiFinity sliding system creates large transparent surfaces that bring the interior seamlessly outdoors. Despite its minimal visible profile, the system's strength allows large glass panels to be carried, and its high energy performance makes it a fitting choice for energy-efficient modern architecture.
Profiles can be hidden floor to ceiling and wall to wall. Variants include 2- and 3-rail, Floor Finish (zero threshold with the bottom profile concealed below floor level), open corner and pocket solutions, and a Magnetic Sliding option that lets triple-glazed panels of up to 600 kg be moved manually with little effort.
Performance
- 01
Concealed profiles
Floor to ceiling and wall to wall.
- 02
Magnetic Sliding
Triple-glazed panels up to 600 kg moved by hand.
- 03
Open corner and pocket
Glass-to-glass corners and vents that disappear into the wall.
Specifications
Performance
EX-06.01- Uw
- 0.8 W/m²K
- Air permeability
- Class 4 (600 Pa)
- Water tightness
- Class E750 (750 Pa)
- Wind resistance
- Class C5 (2000 Pa)
- Acoustics Rw (C;Ctr)
- 46 (-1;-3) dB
- Opening and closing durability
- Class 3
- Burglar resistance
- RC2, PAS 24
Dimensions
EX-06.02- Vent height
- 1800–4000 mm
- Vent width
- 1000–3500 mm
- Max. vent weight
- 750 kg (fixed: 1200 kg)
- Min. interlock width
- 35 mm
- Frame depth
- 148 mm (2-rail) / 236 mm (3-rail) / 325 mm (4-rail)
- Glazing thickness (vent)
- 36–54 mm
Documents
Gallery
01 / 03
02 / 03
03 / 03
Specify HiFinity.
Request catalogues, technical data sheets, samples or a quotation. Tell us about the project and the quantities involved.
