SlimLine 38
Slimness, elegance and comfort
- Uf
- 1.8W/m²K
- Min. frame + vent width
- 72.5mm
- Max. vent weight
- 160kg
01 — Overview
Overview
SlimLine 38 is a highly insulated aluminium door system that combines superior comfort with a minimalist design. Its slim steel look, with optional triple glazing, suits new buildings and contemporary renovations equally well.
Classic and Ferro designs and a burglar-resistant version are offered, with options for concealed hinges, hidden drainage, low and zero thresholds and panic exit.
02
Specifications
Performance
EX-06.01- Uf
- 1.8 W/m²K
- Air permeability
- Class 4 (600 Pa)
- Water tightness
- Class 8A (450 Pa)
- Wind resistance
- Class C3 (1200 Pa)
- Acoustics Rw (C;Ctr)
- 45 (-1;-5) dB
- Opening and closing durability
- Class 6
- Burglar resistance
- RC2, PAS 51
- Fire resistance
- EW 57
Dimensions
EX-06.02- Depth (frame / vent)
- 99 mm / 86 mm
- Max. vent height
- 3000 mm
- Vent width
- 750–1400 mm
- Max. vent weight
- 160 kg
- Max. glass weight
- 300 kg
03
Documents
Gallery
01 / 02
02 / 02
Sheet 09 — Enquiry
Specify SlimLine 38.
Request catalogues, technical data sheets, samples or a quotation. Tell us about the project and the quantities involved.
