MasterLine 10
No compromise
- Uf
- 0.96W/m²K
- Max. vent weight
- 250kg
- Max. vent height
- 3000mm
01 — Overview
Overview
Thanks to their sustainable design and excellent security, MasterLine 10 aluminium doors are an ideal choice for low-energy and passive buildings. The system's patented technology ensures minimal air infiltration and optimum thermal insulation.
Offered in a Functional design and a High Insulation + version, with options such as hidden drainage, a drain profile, low threshold, access control and slow closing.
02
Specifications
Performance
EX-06.01- Uf
- 0.96 W/m²K
- Air permeability
- Class 4 (600 Pa)
- Water tightness
- Class 9A (600 Pa)
- Wind resistance
- Class C3 (1200 Pa)
- Acoustics Rw (C;Ctr)
- 40 (-1;-5) dB
- Opening and closing durability
- Class 8
- Burglar resistance
- RC2
Dimensions
EX-06.02- Depth (frame / vent)
- 97 mm
- Max. vent height
- 3000 mm
- Vent width
- 500–1400 mm
- Max. vent weight
- 250 kg
- Max. glass weight
- 1200 kg
- Min. frame + vent width
- 162 mm
03
Documents
Gallery
01 / 03
02 / 03
03 / 03
Sheet 09 — Enquiry
Specify MasterLine 10.
Request catalogues, technical data sheets, samples or a quotation. Tell us about the project and the quantities involved.
