ConceptFolding 68
Endless enjoyment
- Leaves
- 2–8
- Max. vent height
- 2500mm
- Uw
- 1.4W/m²K
01 — Overview
Overview
The elegant ConceptFolding 68 folding system delivers maximum space efficiency and slim lines. With up to eight leaves, it removes the boundary between inside and outside.
A Functional design, High Insulation version and burglar-resistant version are available, with options for hidden drainage, a drain profile and low or zero thresholds.
02
Specifications
Performance
EX-06.01- Uw
- 1.4 W/m²K
- Air permeability
- Class 4 (600 Pa)
- Water tightness
- Class 9A (600 Pa)
- Wind resistance
- Class B3 (1200 Pa)
- Acoustics Rw (C;Ctr)
- 40 (-2;-4) dB
- Opening and closing durability
- Class 3
- Burglar resistance
- RC2, PAS 24
Dimensions
EX-06.02- Vent height
- 800–2500 mm
- Vent width
- 400–1200 mm
- Max. vent weight
- 120 kg
- Depth
- 68 mm
- Glazing thickness (vent)
- 12–55 mm
03
Documents
Gallery
01 / 02
02 / 02
Sheet 09 — Enquiry
Specify ConceptFolding 68.
Request catalogues, technical data sheets, samples or a quotation. Tell us about the project and the quantities involved.
