VEKAMOVE 76
Sliding system for compact living
- Ud (3.00 × 2.40 m)
- 0.817W/m²K
- Max. element width
- 4200mm
- New PVC profiles
- 6
Overview
VEKAMOVE 76 extends the VEKA range with a sliding system for space-saving room concepts. Sliding doors and windows made from it do not open inwards, creating more usable space and letting plenty of light in — ideal for apartments of every size and for balconies.
A circumferential centre gasket as standard gives a high level of tightness with contemporary insulation values, so the system also suits multi-storey commercial and private buildings. Only six new PVC profiles are needed, welded, to produce sliding doors and sliding windows economically.
Who it is for
Only six new profiles
- 01Sliding doors and sliding windows produced economically from just six new PVC profiles, welded.
- 02Circumferential centre gasket as standard for high tightness.
- 03Suitable for multi-storey commercial and private buildings.
Specifications
Technical data
EX-07.01- Build depth
- Sash: 76 mm; frame: 150 mm
- Min. face width
- Passage: 152 mm; fixed: 71 mm; centre: 122 mm
- Max. glazing thickness
- 48 mm
- Max. element width / height
- 4200 / 2480 mm
- Ud
- 0.817 W/m²K (element 3.00 × 2.40 m, Ug 0.6, ψ 0.04)
- Uw
- 0.831 W/m²K (element 2.50 × 1.25 m, Ug 0.5)
- Wind-load resistance
- Up to class B3
- Driving-rain tightness
- Up to class 9A
- Air permeability
- Up to class 4
- Burglar resistance
- Up to RC2
- Wall thickness
- Class A to DIN EN 12608-1
Gallery
01 / 03
02 / 03
03 / 03
Other lines
PVC Windows & Doors range
SOFTLINE 82 MD
Three gaskets for the highest energy demands
SOFTLINE 82 AD
Outstanding energy saving, long life, security
SOFTLINE 76 MD
Three gaskets, economical production
SOFTLINE 76 AD
Balance of energy and cost efficiency
SOFTLINE 70 AD
The classic of the VEKA range
SOFTLINE 82
High-performance entrance door
Specify VEKAMOVE 76.
Request catalogues, technical data sheets, samples or a quotation. Tell us about the project and the quantities involved.
