IN-04 — Sanitary Ware

Countertop Basins

Vessel basins for vanity tops

Collections: 17
Widths: 30–90cm
Fine fire clay: FFC

01 — Overview

Countertop basins sit on a vanity top, a stone slab or a timber shelf and become the focal point of the room. The collections run from compact round bowls such as Daphne and Vision to long, shallow forms like Edge, Premium and Floppy, with soft-edged pieces such as Drop, Vitale and Infinity in between.

The basins are made in FFC (fine fire clay). Most are gloss white; Bold, Premium, Premium Class, Arcade, Vision, Vision Class, Drop, Drop Slim, Floppy and Daphne add matt black, anthracite or matt white versions, and the 60 cm Premium and Premium Class are offered in thirteen glaze colours. The Deep collection also comes in Crypto, Decorated and Plate Up versions.

Each model has a technical sheet with box size, volume, weight, pallet quantity and an installation drawing, and 3D files are available for design work.

Performance

01
Wide choice of forms
Round, oval, rectangular, asymmetric and sculpted basins.
02
Colour versions
Matt black, anthracite and matt white on many models; 13 colours for Premium and Premium Class 60 cm.
03
Technical sheets
Installation drawing, box size, volume, weight and pallet quantity for every code.
04
3D files
3DS, OBJ, IGES, FBX, STL and STEP for designers.

Applications

Vanity tops and stone slabs
Hotel bathrooms
Restaurant and retail washrooms
Residential bathrooms

Specifications

Collections

IN-04.01

Models: Deep, Bold, Premium, Premium Class, Arcade, Elegance, Edge, Vision, Vision Class, Drop, Drop Slim, Floppy, Vitale, Infinity, Daphne, Beta, Delta

Deep

IN-04.02

16643 · Washbasin, 43 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 10.60 kg (±5 %) · 22 pcs/pallet
316643 · Washbasin, 43 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 10.60 kg (±5 %) · 22 pcs/pallet
6643 · Washbasin, 43 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 10.60 kg (±5 %) · 22 pcs/pallet
6843 · Washbasin, 43 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 10.60 kg (±5 %) · 22 pcs/pallet
306643 · Washbasin, 43 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 10.60 kg (±5 %) · 22 pcs/pallet

Bold

IN-04.03

6860 · Washbasin, 60 cm: 630 × 430 × 140 mm (box) · 0.038 m³ · 12.35 kg (±5 %) · 20 pcs/pallet
16860 · Washbasin, 60 cm: 630 × 430 × 140 mm (box) · 0.038 m³ · 12.35 kg (±5 %) · 20 pcs/pallet
6750 · Washbasin, 50 cm: 530 × 400 × 130 mm (box) · 0.028 m³ · 9.40 kg (±5 %) · 36 pcs/pallet · Colours: Gloss White, Matt Black
16750 · Washbasin, 50 cm: 530 × 400 × 130 mm (box) · 0.028 m³ · 9.40 kg (±5 %) · 36 pcs/pallet · Colours: Gloss White, Matt Black
6740 · Washbasin, 40 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 7.20 kg (±5 %) · 22 pcs/pallet · Colours: Gloss White, Matt Black, Matt White
6736 · Washbasin, 36 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 5.38 kg (±5 %) · 22 pcs/pallet · Colours: Gloss White, Matt Black, Matt White

Premium

IN-04.04

6260 · Washbasin, 60 cm: 600 × 400 × 130 mm · 0.031 m³ · 11.2 kg (±5 %) · 32 pcs/pallet · Colours: Gloss White, Matt Grey, Amber Green, Matt Orange, Sahara, Mocha, Matt Black, Mint Green, Matt White, Ice Blue, Powder Pink, Anthracite, Lilac
6290 · Washbasin, 90 cm: 900 × 400 × 130 mm · 0.047 m³ · 15.7 kg (±5 %) · 14 pcs/pallet · Colours: Gloss White, Matt Black

Premium Class

IN-04.05

16260 · Washbasin, 60 cm: 600 × 400 × 130 mm · 0.031 m³ · 11 kg (±5 %) · 32 pcs/pallet · Colours: Gloss White, Matt Grey, Amber Green, Matt Orange, Sahara, Mocha, Matt Black, Mint Green, Matt White, Ice Blue, Powder Pink, Anthracite, Lilac
16270 · Washbasin, 70 cm: 700 × 400 × 130 mm · 0.037 m³ · 12 kg (±5 %) · 14 pcs/pallet · Colours: Gloss White, Matt Black

Arcade

IN-04.06

4265 · Washbasin, 65 cm: 675 × 465 × 145 mm (box) · 0.046 m³ · 12.4 kg (±5 %) · 40 pcs/pallet · Colours: Gloss White, Matt Black, Anthracite

Elegance

IN-04.07

4360 · Washbasin, 60 cm: 600 × 450 × 115 mm · 0.038 m³ · 13.5 kg (±5 %) · 24 pcs/pallet

Edge

IN-04.08

6440 · Washbasin, 40 cm: 400 × 400 × 110 mm · 0.024 m³ · 8.6 kg (±5 %) · 24 pcs/pallet
6455 · Washbasin, 55 cm: 550 × 450 × 110 mm · 0.044 m³ · 14.4 kg (±5 %) · 32 pcs/pallet
6490 · Washbasin, 90 cm: 900 × 450 × 110 mm · 0.044 m³ · 22.2 kg (±5 %) · 14 pcs/pallet

Vision

IN-04.09

6342 · Washbasin, 42 cm: Ø 420 × 130 mm · 0.03 m³ · 6.3 kg (±5 %) · 22 pcs/pallet · Colours: Gloss White, Matt Black, Anthracite

Vision Class

IN-04.10

16342 · Washbasin, 42 cm: Ø 420 × 130 mm · 0.03 m³ · 6.2 kg (±5 %) · 22 pcs/pallet · Colours: Gloss White, Matt Black, Anthracite

Drop

IN-04.11

4465 · Washbasin, 65 cm: 650 × 450 × 150 mm · 0.069 m³ · 15.9 kg (±5 %) · 24 pcs/pallet · Colours: Gloss White, Matt Black

Drop Slim

IN-04.12

4365 · Washbasin, 65 cm: 650 × 450 × 150 mm · 0.069 m³ · 14.2 kg (±5 %) · 24 pcs/pallet · Colours: Gloss White, Matt Black

Floppy

IN-04.13

16042 · Washbasin, 42 cm: 420 × 270 × 110 mm · 0.027 m³ · 6.5 kg (±5 %) · 35 pcs/pallet
16050 · Washbasin, 50 cm: 500 × 360 × 110 mm · 0.033 m³ · 10.2 kg (±5 %) · 36 pcs/pallet
6042 · Washbasin, 42 cm: 420 × 270 × 110 mm · 0.027 m³ · 6.5 kg (±5 %) · 35 pcs/pallet
6050 · Washbasin, 50 cm: 500 × 360 × 110 mm · 0.033 m³ · 9.9 kg (±5 %) · 36 pcs/pallet · Colours: Gloss White, Matt Black, Anthracite
6075 · Washbasin, 75 cm: 750 × 360 × 110 mm · 0.045 m³ · 13.5 kg (±5 %) · 18 pcs/pallet

Vitale

IN-04.14

4660 · Washbasin, 60 cm: 600 × 435 × 185 mm · 0.048 m³ · 14.3 kg (±5 %) · 24 pcs/pallet

Infinity

IN-04.15

6160 · Washbasin, 60 cm: 600 × 380 × 110 mm · 0.036 m³ · 11.1 kg (±5 %) · 24 pcs/pallet

Daphne

IN-04.16

53710 · Washbasin, 70 cm: 700 × 410 × 140 mm · 0.048 m³ · 18.1 kg (±5 %) · 16 pcs/pallet
53709 · Washbasin, 50 cm: 500 × 420 × 140 mm · 0.039 m³ · 12.8 kg (±5 %) · 22 pcs/pallet
53708 · Washbasin, 43 cm: 430 × 360 × 140 mm · 0.03 m³ · 12 kg (±5 %) · 33 pcs/pallet
53706 · Washbasin, 33 cm: 330 × 280 × 115 mm · 0.017 m³ · 7.1 kg (±5 %) · 51 pcs/pallet
53699 · Washbasin, 43 cm: Ø 430 × 120 mm · 0.035 m³ · 7.6 kg (±5 %) · 22 pcs/pallet
53698 · Washbasin, 30 cm: Ø 300 × 100 mm · 0.015 m³ · 3 kg (±5 %) · 51 pcs/pallet · Colours: Gloss White, Matt Black, Anthracite

Beta

IN-04.17

6240 · Washbasin, 40 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 8.00 kg (±5 %) · 22 pcs/pallet
6340 · Washbasin, 40 cm: 450 × 460 × 160 mm (box) · 0.033 m³ · 7.50 kg (±5 %) · 22 pcs/pallet
