EX-09 — Premium tiles
← Back to Roofing Tiles
İnova
The modern choice
- Breaking load ± 20
- 300kgf
- Coverage
- 15pcs/m²
- Tile size
- 230 × 410mm
01 — Overview
Overview
İnova brings a modern look to the clay tile. Its wide channels ease water run-off, and its interlocking edges keep the roof reliably watertight.
Micronised clay gives a surface that resists dirt and a strength well above the standard. İnova shares its ridge, hip and ventilation fittings with the Ultra.
02
Performance
- 01
Modern design
A contemporary profile in natural clay.
- 02
Clean surface
Micronised clay resists dust and dirt.
- 03
Long life
Breaking resistance above the standard.
- 04
Improved watertightness
Wide channels and interlocking edges.
03
Applications
- Contemporary houses
- Residential developments
- Villas
04
Specifications
Tile
EX-09.01- Dimensions
- 230 × 410 mm
- Weight
- 2950 g (± 100 g)
- Laying
- Straight
- Breaking load
- 300 kgf (± 20 kgf)
- Coverage
- 15 pcs/m²
- Nail hole
- 6 mm
- Batten gauge
- 336–338 mm (eaves to second batten 30 cm)
- Recommended pitch
- ≥ 33 %
Packing
EX-09.02- Pack
- 6 pcs
- Pallet
- 300 pcs, approx. 900 kg
Colours
EX-09.03- Available in
- Natural clay red, Antrasit Gri, Dorlion Ateşi
Gallery
01 / 03
02 / 03
03 / 03
Sheet 09 — Enquiry
Specify İnova.
Request catalogues, technical data sheets, samples or a quotation. Tell us about the project and the quantities involved.
